8/12/27 and 8/13/27 - VFD/PLC (Variable Frequency Drives and Programmable Logic Controllers) - Virtual

Master VFD and PLC fundamentals with a focus on field-ready skills. Learn hands-on navigation, accel/decel ramps, and I/O wiring without being dependent on a manual.

We'll demystify PLC logic by showing you how to read programs and troubleshoot the entire system—PLC, VFD, and HMI—as a single unit. Become a better, higher-earning electrician with JCR.

Live online instruction via Zoom.

August 12, 2027: 12:00–4:00 p.m.; August 13, 2027: 9:00 a.m.–1:00 p.m. Eastern Time • Live virtual via Zoom • Both days required

LIVE VIRTUAL · INSTRUCTOR VICTOR RING

Register for this class

Workshop Details

Live virtual class via Zoom. Joining instructions will be provided before class.

Workshop Date & Location

Virtual

August 12, 2027

Schedule:

August 12, 2027: 12:00–4:00 p.m.; August 13, 2027: 9:00 a.m.–1:00 p.m. Eastern Time

Join Zoom a few minutes before your scheduled start time

What's Included

The complete package

8 Hours Live Instruction

Full training with Victor Ring (1 day in-person or 2 half-days virtual)

Course Workbook

Detailed reference materials you keep

NC Board Reporting

Reported to the NC Board within 5 business days of workshop completion.

FREE 8-Hour Online Course

Includes an additional 8-hour self-paced online course at no extra cost.

What You'll Learn

VFD & PLC Fundamentals

Variable Frequency Drives

Hands-on menu navigation so you're not dependent on a manual during a late-night service call. We'll cover drive setup, accel/decel ramps, I/O wiring, and fault codes — what they're actually telling you and how to troubleshoot without masking the real problem.

Programmable Logic Controllers

PLCs aren't about programming — they're about logic you already know. If a contact is closed AND another is closed, the coil energizes. That's Boolean logic, and you've been doing it your whole career. We'll focus on how to read a PLC program in the field to find the rung controlling the output you're chasing. Then we'll tie it together — PLC, VFD, and HMI working as one system — because that's what you're actually working on out there.

Frequently Asked Questions

Do I need to bring my code book?

Yes. Bring your 2020 NEC for reference during the workshop.

How do I access my free bonus online course?

After the workshop, you’ll receive an email with login instructions for your My Account portal, where you can access the included bonus online course.

When will my CEU hours be reported?

We report to the NC Board within 5 business days of workshop completion. Multi-state reporting available for $25/state.

Can I get credit in states other than NC?

Yes! Add multi-state reporting for $25 per additional state during checkout.

What is your cancelation policy?
